Bipolar power supply lite 0.5A

Description

Bipolar power supply lite 0,5A is high quality, linear, fully discrete power supply. Designed to fulfil requirements of music lovers. Current capabilities of 0,5A are able to supply most headphone amplifiers, DAC analog stages or preamplifiers.

Main features:

• discrete solution designed by MuzgAUDIO
• voltage reference based on LED
• smoothing capacitance 4700uF
• advanced PCB design for best noise reduction and heat dissipation
• high quality components

Parameters:

• adjustable output voltage in range: 12 – 24V
• current capability: 0.5A
• power dissipation up to 2W – more possible with bigger heatsink
• dimensions 92 x 60mm

To create high quality +/-15V power supply you can buy 16VA transformer available on our shop!
